The LA76832 is an I2C bus controller IC that supports the NTSC and aim for rationalization of color TV set design, improved manufacturability and lower total costs.
Parametrics
LA76832 maximum ratings: (1)Maximum supply voltage V8 max: 7.0 V; (2)Maximum supply current, I18 max, 25 mA; I25 max: 35 mA; (3)Allowable power dissipation Pd max Ta≤65℃: 1.6 W; (4)Operating temperature Topr: -10 to +65 ℃; (5)Storage temperature Tstg: -55 to +150 ℃.
Features
LA76832 features: (1)IF supply current I8: when V8 = 5V, V3 = 2.5V, 55.0mA min, 65.0typ, 75.0 mA max; (2)RGB supply current V18: when I18 = 19mA, 8.0 V typ; (3)Horizontal supply voltage V25: when I25 = 27mA, 5.0 V typ; (4)CCD supply current I31: when I31 = 5V, 5.6 mA typ; (5)Video supply current I43: when I43 = 5V, 150 mA.
